OEM-B502

0,1–600 U/min

0,69–12.000 ml/min

Optionaler Pumpenkopf:

YZ35-II

Online-Beratung

Herunterladen

Produktvorstellung

YZ35-II pump head housing is produced with high-pressure die-casting aluminum, ensuring high strength and good consistency.
Equipped with a standard electromagnetic sensor that outputs a cover-open to stop signal to enable the cover-open to stop function.
The optimized tubing clamp structure allows for easy installation and removal of the tubing, preventing abnormal damage to the tubing.
Added a lever limiter to securely fix the lever, preventing loosening due to vibrations.
304 stainless steel roller assembly, resistant to liquid leakage and corrosion.

Geschwindigkeitsbereich	0,1–600 U/min
Geschwindigkeitsregelung	External input pulse frequency speed regulation
subdivision settings	200~51200 (factory default 3200)
Stromversorgung	AC220V(±10%) (≥300W) OEM-B502
Logic input voltage	5V
Ambient temperature	0–40 °C
Ambient humidity	≤80%RH, no condensation
Arbeitsumfeld	Keep away from heating equipment, avoid dust, oil mist, corrosive gases and strong vibration sites.

Pump Head	Schläuche	ID×Wall thickness (mm)	ml/r	Flow rate(mL/min) (0.1-600rpm)	Tubing pressure resistance(Mpa)		Material	Gewicht (kg)
					Fortlaufend	zeitweise
YZ35-II	26#	6,4 × 3,3	6.9	0,69–4200	0.27	0.2	Cast aluminum alloy	2.8
	73#	9,6 × 3,3	12.3	1,23–7400	0.27	0.2
	82#	12,7 × 3,3	20	2-12000	0.14	0.1

Tubing Installation Demonstration
